Precision Injection Mold and Tooling Solutions for Investment Castings


AS9100 quality manual, capacities and equipment list

tooling and solutions for investment castings

Who we are:

We have over 30 years of Tool and Die experience, supplying complex tool designs, injection molds and fixtures for wax and polymer patterns used to manufacture investment cast turbine engine and aerospace components. We take pride in knowing that our design and manufacturing abilities are industry leading and that we have shattered the paradigm of traditional tool design and mold making. Our processes for building investment casting tooling has been standardized offering our customers standardized solid model designs and tools that exceed expectations and industry standards.



We are beyond the norm of mold and pattern makers, we are designers that design and build solutions to help you produce the best possible wax or polymer pattern, part or investment casting.


Mission Statement –  Our TEAM is committed to providing our customers the best possible service, quality and delivery through personal relationships, communication and innovative improvement of injection mold making and tooling technologies.


Training – We are always searching for new candidates to join our TEAM and learn our highly specialized methods of design and manufacturing.  We offer technical design, manufacturing and metrology training for individuals that have the passion to learn and excel in a CAD/CAM/CMM manufacturing  environment.


Employment Benefits – We offer a full compensation package with medical insurance and vacation benefits.


Quality System – We operate utilizing the structure of the AS9100 and ISO 9000 systems as the center of all processes.




What our Customers are Saying:


  • "When the primes visit us, they only see your design models and your injection molds "
  • "Your designs have ingenuous ideas, our operators are getting spoiled"
  • "You are definitely setting the quality bar"
  • "Your team offers the caliber of engineering usually only found with larger OEM's"
  • "We are using your wax pattern assembly fixture design, as our internal standard"m

What we do:

 Support Solutions:

  • Pattern Assembly Design and Consulting
  • Tool and Fixture Design
  • Print to Part Modeling
  • 3D-Scan to Part Modeling
  • Portable Metrology
  • Tool and Fixture Reworks

Injection Molds:

  • Gate, Sprue and Reworks
  • Complex Structural
  • Turbine Vane - Blade - Stator
  • Medical Orthopeadics
  • Manual - Semi - Automatic
  • Rapid Prototype
  • Ceramic
  • Soluble

Fixtures:

  • Production Inspection
  • Pattern Assembly
  • Machining
  • Straightening
  • Pattern Setters

Common Materials:

  • 7075-T651
  • QC-7
  • NAK-55
  • P20, D2, H13, S7
  • Stainless Steel
  • Epoxy

Tooling Services

Production - Rapid Prototype INJECTION MOLDS

3D mold designs

Inspection - Production ASSEMBLY FIXTURES

Investment Castings, SLA, Qickcast, Wax Patterns - Leaders in functionality

Rapid - Production CNC MACHINING

High speed CNC machining using only HAAS

Contact Us

Contact Us

We deliver and support every product!

We would love to have you as one of our very satisfied customers so just call or e-mail us and and we will come to you.



Sales, Engineering, Quality       Gregg Turner 971-678-0232

gturner@pacificpatterntech.com


Program Manager                       Chad Turner 971-678-0242

cturner@pacificpatterntech.com


Sales, Administration, HR             Jodi Turner 971-678-0231

jturner@pacificpatterntech.com


1445 NE Miller Street, Suite A5 McMinnville, Oregon 97128, United States

971.678.0232
